Main Performance Parameters

Continuous Operating Temperature 260℃/500℉
Temperature Endurance 500℃
Off-Self Time  10 s
Horizontal Flame Test ≤30S
Max. Short Term Exposure 1300℃
Design Build  Braided fiberglass substrate coated with silicone rubber
Reactions  Resists most acids and water. Unaffected by solvents and fire.
Design Capabilities Excellent thermal protection; flexible;custom silicone thicknesses available
Size/Size Range  1/4″~5″(6.5mm-127mm)
Breakdown Voltage In normal conditions, alternating current 50HZ can reach 10.000V~12.000V
Nominal Wall Thickness 1mm-5mm(1/25″-1/5″)
Flexibility  Outstanding
Durability  Outstanding
Color  Custom colors available by special order.

Characteristics of Fire Sleeve:
Fire sleeve is the perfect cover to protect hydraulic hoses,oil lines and wiring bundles.
Made of braided fiberglass yarns in a flecible substrate, it is then coated with a high quality silicone rubber. Resistant to hydraulic fluids, lubricating oils, and fuels. The fire sleeve is designed to protect hoses, wires and cables from the hazards of high heat and occasional flame. The Fire Sleeve protects continuously to 260℃/500℉ and will withstand a molten splash at 1300℃.

specification

Code I.D.(mm) Thickness(mm) Length:m/roll
IFH-012  Φ12±0.5 1.6±0.2 20
IFH-015  Φ15±0.5 1.6±0.2 20
IFH-020  Φ20±0.5 1.6±0.2 20
IFH-025  Φ25±0.8 1.8±0.4 20
IFH-030  Φ30±0.8 1.8±0.4 20
IFH-035  Φ35±0.8 1.8±0.4 20
IFH-040  Φ40±1.0 2.0±0.5 20
IFH-045  Φ45±1.0 2.0±0.5 15
IFH-050  Φ50±1.0 2.0±0.5 15
IFH-055  Φ55±1.2 2.0±0.5 15
IFH-060  Φ60±1.2 2.2±0.5 15
IFH-065  Φ65±1.2 2.2±0.5 15
IFH-070  Φ70±1.5 2.2±0.5 15
IFH-075  Φ75±1.5 2.5±0.5 15
IFH-080  Φ80±1.5 2.5±0.5 15
IFH-085  Φ85±2.0 2.5±0.5 15
IFH-090  Φ90±2.0 3.0±0.5 15
IFH-100  Φ100±2.0 3.0±0.5 15
