The pvc fiber reinforced steel wire hose is made of high-quality PVC. It’s an anti-aging synthetic material. While the strengthened helix galvanized steel wire is embedded in the soft tubing inner wall. Then adding the enhanced fibre mesh, which combines the features of the steel wire tubing and the fiber reinforced tube. Thus it greatly improves the compressive performance of the product.

PVC fibre and steel wire reinforced hose has a strong structure. That’s because of the reinforce. The fibre reinforce layer makes the hose more flexible. While wire reinforce makes the fibre and steel wire composite hose more strong. Then both of them offer a higher pressure resistance. Thus such reinforced PVC hose can work at heavy duty. But the normal PVC hose can’t. Besides, steel wires make the hose can bear high external force. We have tested that it remains the previous shape even an adult step on.

Steel Wire Fibre Hose Structure:

Tube and cover: transparent PVC

Reinforcement: steel wire spiral & polyester fibre braiding

Reinforced PVC Hose Application:

The PVC steel wire spring and fibre composite hose hose is widely used for suction and discharge of water,oil and powdery articles. While it’s serves in industry, agriculture, engineering, foodstuffs and sanitation lines. The hose used for foodstuffs is made from special food grade pvc. Besides, it is non-toxic, light, without odor and transparent.

The food grade PVC wire spring and fibre composite hose can be used for conveying milk, beverage, distilled liquor, beer, jam and other foods. We can also insert the cooper wire into hose.This hose can avoid the block of the flowing in the hose due to static. Then protect users from getting electric shock or electric current impingement.

Wire and Fibre Reinforced PVC Hose Features:

Light in weight, flexible with small bending radius.

Durable against the external impact, chemical and climate.

Transparent, easy to check the contents.

Anti-UV,anti-aging

Long working life

Heavy duty, higher working pressure

Temperature : -10℃(-50℉) to 65℃(+150℉)

steel wire hose usage
