Fracking hose is to connect into frack tanks. The 400 PSI high pressure hose is designed to discharge or convey water and oil slurry mixtures. The tube is made from nitrile, while the cover is an EPDM and SBR blend. The oilfield hose can withstand high pressure up to 400 PSI. Besides, it has excellent weather and abrasion resistant. Therefore, it can work in harsh conditions. For example, the outdoor use. Then the oil resistant Class C tube can handle gasoline and other petroleum products with aromatic content up to 50%. Besides, such rubber hose has excellent corrosion resistance. Thus it can deal with the acid mud or other corrosive fluids.

Fracking Hose Structure:

Tube: Black, smooth, nitrile rubber
Reinforcement: 6 plies of high tensile fabric, helix steel wire skeleton with anti-static wire
Cover: weather and abrasion resistant synthetic rubber

Frac Hose Application:

High pressure frac hose is to transfer types of hydraulic fracking fluids from tank trucks. It also ideal for the demands of high working pressures of hydraulic fracturing operations.

Temperature:-32°C to +82°C (-90°F to +180°F).

Frac Hose Features:

Weather and abrasion resistant cover

Designed for aromatic content up to 50%

Heavy duty use to 400 PSI
